Model No: MF-US2
MF-US2 U-shape Inclined Screw Conveyor
Power supply:3P AC208-415V 50/60Hz
Charging angle:Standard 45 degree,30~60 degree are also available.
Charging Height:Standard 1.85M,1~5M could be designed and manufactured.
Square hopper,with vibrator,Round hopper could be designed and manufactured.
Fully stainless steel structure,contact parts SS304.
Other Charging Capacity could be designed and manufactured.
The feeding system can be customized with no hopper,just connecting directly to
other machines.
U shape trough,there is stainless steel cap on the trough hinged by buckle
with good sealing in the middle.Easy to remove and clean.
Charging angle:Standard 45 degree,30~60 degree are also available.
Charging Height:Standard 1.85M,1~5M could be designed and manufactured.
Square hopper,with vibrator,Round hopper could be designed and manufactured.
Fully stainless steel structure,contact parts SS304.
Other Charging Capacity could be designed and manufactured.
The feeding system can be customized with no hopper,just connecting directly to
other machines.
U shape trough,there is stainless steel cap on the trough hinged by buckle
with good sealing in the middle.Easy to remove and clean.
Quantity :
Technical Parameters
| Model | MF-US2-2K | MF-US2-3K | MF-US2-5K | MF-US2-7K | MF-US2-8K | MF-US2-12K |
| Charging Capacity | 2m³/h | 3m³/h | 5m³/h | 7m³/h | 8m³/h | 12m³/h |
| Diameter of pipe | φ102 | φ114 | φ141 | φ159 | φ168 | φ219 |
| Total power | 0.59KW | 0.79KW | 1.54KW | 2.24KW | 2.24KW | 3.04KW |
| Total Weight | 100kg | 130kg | 170kg | 200kg | 220kg | 270kg |
| Hopper Volume | 100L | 200L | 200L | 200L | 200L | 200L |
